Akvo AA500
Akvo AA500
AQUAAERO AA500 atmospheric water generators make water using their proprietary ground breaking air-to-water technology that creates unlimited, clean drinking water from the moisture in the air.
Download Brochure
- Make: Akvo Atmospheric Water Systems
- Model:180KIDM
- Fabrication body:Made of SS
- Temperature Rating:15-55°C
- Humidity Rating:40 - 99 % RH
- Electrical Power:380-440V, 50Hz-60HZ, 3 Phase
- Nominal Amps rating@60HZ:12A @ 30C, 80% RH
- Nominal Amps rating@50HZ:10A @ 30C, 80% RH
- Pressure:Low s i d e Pressure 60-130 PSIG
- Water Production Per Day:500 LPD @ 30C, 80% RH
- Nominal Energy Consumption (KWH) @60HZ:5.5 KW @ 30C, 80% RH
- Nominal Energy Consumption (KWH) @50HZ:4.5 KW @ 30C, 80% RH
- Sound:<75 DBA
- Refrigerant:R407C
- Compressor type:Scroll compressor
- Compressor Make:Emerson/Danfoss
- Compressor Oil:POE
- Compressor Speed:3000 rpm
- Condenser Type:Forced-Air Cooled, Copper Tube, Plane Al Fins
- Expansion Device:Thermostatic Expansion Valve
- Evaporator Type:Copper Tube, Blue Al Fins-Hydrophilic
- Cooling System:Air Cooled
- Machine should not be exposed to direct sun light/rain for higher efficiency of the machine, Shed should be provided.
.png){kind=icon}
- Communication:GSM (default)/WIFI
- Server:GCP based
- Location tracking:GPS based
- Website & App:Website platform
- Data Analytics:Visualize and analyze data online
- Composite Filter (Pre & Post carbon filter)
- Remineralisation filter
- Sediment Carbon Filter
- UV Light, 11 watt
- Hot & cold water feature
- Air filter: HDPE Backed with SS metal 10-15 microns
- AWG Dimensions (LXWXH) (cm):112x150x129
- Net Weight (kg):200±20
- Inbuilt tank capacity (Ltr):120
- Shipping Dimensions (LxWxH) (cm):125 x160x140
- Shipping Weight (kg):240±50
- Temperature Sensor: For coil temperatures, 2 Nos indicate temperature to know if machine running per design intent for technical assessment to know if machine is running out of envelope
- Tank Level Sensor: To indicate Water level To protect pump from dry running
- Fan Modulation: To increase the efficiency of the machine To protect compressor To reduce noise
- Ambient Humidity & Temp: Available on LCD screen in a machine
- Water Generation rate: Water meter installed
- Water Consumption rate: Visualize and analyze data online
The science of making water from air
AQUAAERO Atmospheric Water
Generators depend on the humidity and
temperature.
The water output increases
with an increase in humidity and vice versa.
Warm coastal areas with high humidity are ideal.
